Number of circuits 50000
Beam width 24°
Diameter 50mm
Dimmable Yes
Average life 40000h
Color temperature 4000K
Color rendering Ra 80
Lamp color 840
Lamp base GU5.3
Length 54mm
Luminous intensity 2300cd
Luminous flux 440lm
Brand Philips
Corresponding power 35W
Power factor 0.7
Voltage 12V AC (alternating)
Lamp application General
Power 7W
EAN code 8718291655367
EAN code (extra) 08718291655374
|
lamp base |
GU5.3 |
|
Balloon |
MR16 [MR 16in/50mm] |
|
spec life (hours) |
40000 hr |
|
Nominal life (hours) |
40000 hr |
Technical Light Properties
|
Color code |
827 |
|
Color designation (text) |
Warm white |
|
Beam angle |
36 D |
|
Bundle description |
36D [Medium Beam] |
|
Color Temperature |
2700 K |
|
Luminous flux |
420 Lm |
|
Brightness |
1200 cd |
|
Color Rendering Index |
80 |
|
luminous efficiency |
60.00 Lm/W |
|
Color Temperature |
2700K [CCT 2700K] |
|
Specified luminous flux |
420 Lm |
|
Lm-beh.fact. end of life |
70% |
|
Color consistency |
6 steps |
|
Nominal beam width |
36 D |
|
Luminous flux in cone of 90° |
385 Lm |
Electrical characteristics
|
Power |
7 W |
|
Technical capability |
7 W |
|
Voltage |
12V |
|
Line Frequency |
50-60 Hz |
|
Lamp current |
715mA |
|
Dimmable |
Yes |
|
Equivalent power |
35 W |
|
Rated power |
7.0 W |
|
Start-up time |
0.5 (max) sec |
|
Warm-up Time to 60% Light Outp |
instant full light |
|
Suitable for accent lighting |
yes |
Temperature characteristics
|
T-housing max. |
110 C |
Environmental properties
|
Energy Efficiency Label (EEL) |
a |
Dimension conditions
|
Switching cycle |
50000X |
Dimensions in mm.
|
Total length C |
50mm |
|
Diameter D |
54mm |
Product data
|
Order code |
655381 00 |
|
EOC product code |
871829165538100 |
|
Product name |
MASTER LEDspotLV D 7-35W 827 MR16 36D |
|
Order product name |
MAS LEDspotLV D 7-35W 827 MR16 36D |
|
Quantity per pack |
1 |
|
Packing Quantity |
10 |
|
Packs per outer box |
10 |
|
Barcode on product |
8718291655381 |
|
Barcode on outer box |
8718291655398 |
|
Logistic code(s) |
929000237602 |
|
Net weight per piece |
0.060 kg |
